• Power supply : AC 100–240 V, 3.5 A, 50 Hz/60 Hz
• Power consumption : 300 W (6 W with Standby mode set to Normal, 0.5 W with Standby mode set to Eco*1)
• Display method : Transparent LCD panel (x3, R/G/B)
• Drive method : Active matrix method
• Panel size : 16.0 mm (0.63˝) diagonal (4:3 aspect ratio)
• Pixels : 786,432 (1024 x 768) pixels
• Lens : Manual zoom (1.2x), manual focus lens F=1.6–1.76, f=19.16–23.02 mm, throw ratio: 1.48–1.78:1
• Screen size (diagonal) : 0.76–7.62 m (30–300˝) diagonally, 4:3 aspect ratio
• Resolution : 1024 x 768 pixels *3
• Supported RGB signal : XGA–WUXGA
• Supported video signal : NTSC/PAL/SECAM, 480p/i, 720p, 1080p/i
• Brightness*2 : 4,100 lm (Lamp power: Normal)
• Lamp : 230 W x 1 lamp
• Lamp replacement cycle*4 : Normal: 5,000 hours, Eco1: 6,000 hours, Eco2: 10,000 hours
• Contrast*2: 16,000:1 (all white/all black, Iris: On, Image Mode: Dynamic, Lamp Control: Normal)
• Keystone correction range : Vertical: ± 30 ° (Auto, Manual), Horizontal: ± 15 ° (Manual)
• Installation : Ceiling/floor, front/rear
• Operation noise*2 : Normal: 37 dB, Eco1: 33 dB, Eco2: 28 dB
• Cabinet materials : Molded plastic (PC)
• Dimensions (W x H x D) : 335 x 96 *5 x 252 mm (13 3/16˝ x 3 25/32˝ *6 x 9 29/32˝)
